Aplicación
Líneas aéreas de transmisión y distribución primaria o secundaria.
Tiene menor peso y gran resistencia al esfuerzo mecánico lo cual permite grandes vanos en líneas de transmisión. Los conductores con lubricante son más resistentes a la corrosión, su uso es aconsejable en zonas con atmósferas salinas.
Normas de Fabricación
American Standard-ASTM B 399/B 399M
Normas Técnicas Peruanas-NTP 370.258
International Electrotechnical Commission International Standards-IEC 61089
Construcción
1.- Conductor aleación de aluminio, cableado concéntrico.
2.- Puede fabricarse con o sin lubricante.
3.- El tipo de lubricante usado es Xp3 EL-1100.
Características Eléctricas
Densidad a 20°C | 2.703 kg/dm3 |
Resistencia por temperatura a 20 °C | 0.00360 (°C) |
Resistividad a 20 ° C, máxima | 32,84 Ωmm2 /km |
Coeficiente de expansión lineal, por °C | 23 x10-6(°C) |
Conductividad | 52,5 % IACS |
Modulo de elasticidad Inicial | 50,34 kN/mm² |
Modulo de elasticidad Final | 60,82 kN/mm² |
Condiciones de Servicio
Temperatura ambiente | -5°C – 50°C |
Presión del viento | 80 – 130kg/m^2 |
Aceleración sísmica | 0.12 – 0.05g |
Nivel isoqueraunico | 10 – 18 |
Humedad relativa | 5 – 100% |
American Standard-ASTM B 399/B 399M/Normas Técnicas Peruanas-NTP 370.258
Sección |
Número de
Alambres N º |
Diámetro
alambres mm |
Diámetro
exterior mm |
Peso
Nominal kg / km |
Tracción
mínima kN |
Resistencia
Máxima c.c. a 20 ºC ohm/km |
16 | 7 | 1,71 | 5,12 | 43,8 | 4,94 | 21,111 |
25 | 7 | 2.13 | 6.40 | 68.4 | 7.72 | 1.3511 |
35 | 7 | 2.52 | 7.57 | 95.7 | 10.81 | 0.9651 |
50 | 7 | 3.023 | 9.05 | 136.8 | 15.44 | 0.6755 |
70 | 7 | 3,57 | 10,70 | 191,5 | 20,95 | 0,4825 |
70 | 19 | 2,17 | 10,85 | 191,5 | 20,95 | 0,4825 |
95 | 19 | 2,52 | 12,62 | 261,1 | 29,33 | 0,3573 |
120 | 19 | 2,84 | 14,18 | 329,8 | 37,05 | 0,2828 |
120 | 19 | 2,84 | 14,18 | 329,8 | 37,05 | 0,2828 |
150 | 19 | 3,17 | 15,85 | 412,3 | 46,31 | 0,2263 |
150 | 37 | 2,27 | 15,89 | 412,3 | 46,31 | 0,2263 |
185 | 19 | 3,52 | 17,60 | 508,5 | 57,12 | 0,1835 |
185 | 37 | 2,53 | 17,60 | 508,5 | 57,12 | 0,1835 |
240 | 19 | 4,01 | 20,05 | 659,7 | 71,82 | 0,1414 |
240 | 37 | 2,88 | 20,16 | 659,7 | 71,82 | 0,1414 |
300 | 37 | 3,21 | 22,49 | 826,5 | 92,63 | 0,1134 |
400 | 37 | 3,71 | 25,97 | 1 102,0 | 119,7 | 0,0851 |
ASTM B 399/B 399M Full Size
Code Name |
Area |
Size&Stranding ACSR with equal diameter |
No. And diameter of wires |
Cable diameter |
Weight |
Rated Strength |
Strand Length |
||
Nominal |
Actual |
||||||||
|
MCM |
mm² |
AWG or MCM |
AI/Steel |
mm |
mm |
Kg/km |
kN |
m±5% |
Akron |
30.58 |
15.48 |
6 |
6/1 |
7/1.68 |
5.04 |
42.7 |
4.92 |
3000 |
Alton |
48.69 |
24.71 |
4 |
6/1 |
7/2.12 |
6.35 |
68.0 |
7.84 |
3000 |
Ames |
77.47 |
39.22 |
2 |
6/1 |
7/2.67 |
8.02 |
108 |
12.45 |
2000 |
Azusa |
123.3 |
62.38 |
1/0 |
6/1 |
7/3.37 |
10.11 |
172 |
18.97 |
2000 |
Ananeim |
155.4 |
78.65 |
2/0 |
6/1 |
7/3.78 |
11.35 |
217 |
23.93 |
3000 |
Amherst |
195.7 |
99.22 |
3/0 |
6/1 |
7/4.25 |
12.75 |
273 |
30.18 |
2500 |
Alliance |
246.9 |
125.1 |
4/0 |
6/1 |
7/4.77 |
14.31 |
345 |
38.05 |
2000 |
Butte |
312.8 |
158.6 |
266.8 |
26/7 |
19/3.26 |
16.30 |
437 |
48.76 |
3000 |
Canton |
394.5 |
199.9 |
336.4 |
26/7 |
19/3.66 |
18.30 |
551 |
58.91 |
2500 |
Cairo |
465.5 |
235.8 |
397.5 |
26/7 |
19/3.98 |
19.88 |
650 |
69.48 |
2000 |
Darien |
559.5 |
283.5 |
477 |
26/7 |
19/4.36 |
21.79 |
781 |
83.52 |
2000 |
Elgin |
652.4 |
330.6 |
556.5 |
26/7 |
19/4.71 |
23.54 |
911 |
97.42 |
1500 |
Flint |
740.8 |
375.3 |
636 |
26/7 |
37/3.59 |
25.16 |
1035 |
108.21 |
3000 |
Greely |
927.2 |
469.8 |
795 |
26/7 |
37/4.02 |
28.14 |
1295 |
135.47 |
2500 |
Technical Data
Número de Hilos |
Módulos finales de elasticidad |
Coeficiente de expansión lineal |
||
AL |
Kg/mm^2 |
lb/in^2 |
1/Co |
1/Fo |
7 |
6000 |
8.5 x106 |
23.0 x10-6 |
112.8 x10-6 |
19 |
5700 |
8.1 x106 |
23.0 x10-6 |
112.8 x10-6 |
37 |
5700 |
8.1 x106 |
23.0 x10-6 |
112.8 x10-6 |
61 |
5500 |
7.8 x106 |
23.0 x10-6 |
112.8 x10-6 |
91 |
5500 |
7.8 x106 |
23.0 x10-6 |
112.8 x10-6 |
ASTM B 399/B 399M Reduced Size
Nominal section |
Stranding |
Overall diameter |
Weight |
Rated Strength |
Conductive Resistance |
Capacity |
|
AWG&MCM |
mm^2 |
No.×mm |
mm |
kg/km |
KN |
Ω/Km |
A |
6 |
13.2 |
7/1.55 |
4.65 |
36.2 |
4.18 |
2.5361 |
69 |
4 |
21.1 |
7/1.96 |
5.88 |
57.9 |
6.69 |
1.586 |
93 |
2 |
33.5 |
7/2.47 |
7.41 |
92 |
10.6 |
0.9987 |
123 |
1/0 |
53.5 |
7/3.12 |
9.36 |
146.8 |
17 |
0.62592 |
165 |
2/0 |
67.3 |
7/3.50 |
10.5 |
184.8 |
20.4 |
0.49738 |
190 |
3/0 |
84.9 |
7/3.93 |
11.79 |
233 |
25.7 |
0.3945 |
219 |
4/0 |
107 |
7/4.42 |
13.26 |
294.7 |
32.5 |
0.31188 |
253 |
250 |
126 |
19/2.91 |
14.55 |
346.7 |
38.8 |
0.26509 |
280 |
300 |
152 |
19/3.19 |
15.95 |
416.7 |
46.6 |
0.22059 |
313 |
350 |
178 |
19/3.45 |
17.25 |
487.3 |
52 |
0.1886 |
345 |
400 |
203 |
19/3.69 |
18.45 |
557.5 |
59.5 |
0.16486 |
375 |
450 |
228 |
19/3.91 |
19.55 |
626 |
66.8 |
0.14683 |
402 |
500 |
253 |
19/4.12 |
20.6 |
695 |
74.2 |
0.13224 |
429 |
550 |
279 |
37/3.10 |
21.7 |
766.2 |
83.9 |
0.11995 |
455 |
600 |
303 |
37/3.23 |
22.61 |
831.9 |
91 |
0.11049 |
478 |
650 |
330 |
37/3.37 |
23.59 |
905.5 |
94.9 |
0.1015 |
504 |
700 |
354 |
37/3.49 |
24.43 |
971.2 |
101 |
0.09464 |
525 |
750 |
381 |
37/3.62 |
25.34 |
1045 |
109 |
0.08796 |
549 |
800 |
404 |
37/3.73 |
26.11 |
1109 |
116 |
0.08285 |
569 |
900 |
456 |
37/3.96 |
27.72 |
1250 |
131 |
0.07351 |
612 |
1000 |
508 |
37/4.18 |
29.26 |
1393 |
146 |
0.06597 |
653 |
1250 |
631 |
61/3.63 |
32.67 |
1732 |
179 |
0.05306 |
743 |
1500 |
759 |
61/3.98 |
35.82 |
2082 |
215 |
0.04414 |
827 |
1750 |
886 |
61/4.30 |
38.7 |
2431 |
251 |
0.03781 |
904 |
(*) Note: The values of current rating mentioned in above Table are based on wind velocity of 0.6 meter/second, solar heat radiation of 1200 watt/metre2, ambient temperature of 50° C & conductor temperature of 80°C.
International Electrotechnical Commission International Standards-IEC 61089
Código | Sección Nominal | Stranding | Diámetro total | Peso | Carga de Rotura | Resistencia Eléctrica | Ampacidad* |
mm^2 | No.×mm | mm | kg/km | KN | Ω/Km | A | |
16 | 18.4 | 7/1.83 | 5.49 | 50.4 | 5.43 | 1.7896 | 86 |
25 | 28.8 | 7/2.29 | 6.87 | 78.7 | 8.49 | 1.1453 | 113 |
40 | 46 | 7/2.89 | 8.67 | 125.9 | 13.58 | 0.7158 | 151 |
63 | 72.5 | 7/3.63 | 10.89 | 198.3 | 21.39 | 0.4545 | 200 |
100 | 115 | 7/2.78 | 13.9 | 316.3 | 33.95 | 0.2877 | 266 |
125 | 144 | 7/3.10 | 15.5 | 395.4 | 42.44 | 0.2302 | 305 |
160 | 184 | 19/3.51 | 17.55 | 506.1 | 54.32 | 0.1798 | 355 |
200 | 230 | 19/3.93 | 19.65 | 632.7 | 67.91 | 0.1439 | 407 |
250 | 288 | 19/4.39 | 21.95 | 790.8 | 84.88 | 0.1151 | 466 |
315 | 363 | 37/3.53 | 24.71 | 998.9 | 106.95 | 0.0916 | 535 |
400 | 460 | 37/3.98 | 27.86 | 1268.4 | 135.81 | 0.0721 | 618 |
450 | 518 | 37/4.22 | 29.54 | 1426.9 | 152.79 | 0.0641 | 663 |
500 | 575 | 37/4.45 | 31.15 | 1585.5 | 169.76 | 0.0577 | 706 |
560 | 645 | 61/3.67 | 33.03 | 1778.4 | 190.14 | 0.0516 | 755 |
630 | 725 | 61/3.89 | 35.01 | 2000.7 | 213.9 | 0.0458 | 809 |
710 | 817 | 61/4.13 | 37.17 | 2254.8 | 241.07 | 0.0407 | 866 |
800 | 921 | 61/4.38 | 39.42 | 2540.6 | 271.62 | 0.0361 | 928 |
900 | 1036 | 91/3.81 | 41.91 | 2861.1 | 305.58 | 0.0321 | 992 |
1000 | 1151 | 91/4.01 | 44.11 | 3179 | 339.53 | 0.0289 | 1051 |
1120 | 1289 | 91/4.25 | 46.75 | 3560.5 | 380.27 | 0.0258 | 1118 |
1250 | 1439 | 91/4.49 | 49.39 | 3973.7 | 424.41 | 0.0231 | 1185 |
